Skyjacker 4.5in. Component Box with Dual Rate Long Travel Front and Rear Coils for 20-22 Jeep Gladiator JT

Name: Skyjacker 4.5in. Component Box with Dual Rate Long Travel Front and Rear Coils for 20-22 Jeep Gladiator JT
SKU: ZOHY21842139632
Availability: InStock

$100.00 $1,032.99

Review

Dual-Stage Flexibility: Provides ability to increase articulation at full suspension drop for improved off-road performance, while still delivering a comfortable ride.Truck Specific: Engineered to coordinate specifically with Gladiator's distinctive suspen

Satisfaction 100% Guaranteed
Free shipping on orders over $30
60 day easy Return

Select Rubicon or Non-Rubicon:

Select Engine Type:

SKU: ZOHY21842139632 Category: Spring Lift Kits

Description

Dual-Stage Flexibility: Provides ability to increase articulation at full suspension drop for improved off-road performance, while still delivering a comfortable ride.

Truck Specific: Engineered to coordinate specifically with Gladiator’s distinctive suspension handling characteristics.

Comprehensive System: Component box includes Front Dual Rate Long Travel Coil Springs, Rear Coil Spring, Front Lower Control Arms, Front Adjustable Track Bar, Bump Stop Spacers and Sway Bar End Links.

Note:Will Not Fit Mojave Models

Many states have laws that limit the maximum height of a lifted vehicle. Never exceed the legal height limit.

Learn More

Skyjacker’s 4.5in. Component Box with Dual Rate Long Travel Front and Rear Coils is exclusively designed for the Jeep Gladiator JT and provides superior ride quality and suspension performance from a 4.5-inch lifted platform. This inclusive kit consists of Front Dual Rate Long Travel Coil Springs, Rear Coil Spring, Front Lower Control Arms, Front Adjustable Track Bar, Bump Stop Spacers, and Sway Bar End Links. Additionally, longer front lower control link arms engineered to correct caster angle, while inward offset bend improves turning radius and longer replacement Rear Upper Control Link Arms correct rear drive shaft pinion angle. Dual-flex rate stages offer increased articulation as the suspension drops by expanding flex rate for better off-road performance, yet retaining a comfortable, factory-like ride. Designed to coordinate with Gladiator suspension handling and raises vehicle’s rear one inch to gain a more level stance. Features lifetime warranty.

Installation Notes

Installation Difficulty:
Level 3 Advanced
Installation Time: 5-6 hours

Parts Included

Front Dual Rate Long Travel Coil Springs

Rear Dual Rate Long Travel Coil Springs

Front Lower Arms

Rear Upper Arms

Adjustable Track Bar

Track Bar Bracket

Bump Stop Spacers

Sway Bar End Links

Rear Brake Lines

Warranty

Limited Lifetime Warranty

Specs

For Non-Rubicon EcoDiesel Engine:

Features: Progressive Coil Springs

Shocks Included: Without Shocks

Max Tire Size: 37

Lift Height Range: 4.5 Inch

Included Parts: Bump Stop Extensions, Bump Stops, Coil Springs, Extended Brake Lines, Front Lower Control Arms, Front Track Bar, Rear Upper Control Arms, Sway Bar Endlinks

Shipping Weight: 135lb

Shipping Dimensions: 47in x 14in x 12in (L x W x H)

For Rubicon EcoDiesel Engine:

Features: Progressive Coil Springs

Shocks Included: Without Shocks

Max Tire Size: 37

Lift Height Range: 4.5 Inch

Included Parts: Bump Stops, Coil Springs, Extended Brake Lines, Front Lower Control Arms, Front Track Bar, Front Track Bar Bracket, Rear Upper Control Arms, Sway Bar Endlinks

Shipping Weight: 136lb

Shipping Dimensions: 47in x 14in x 12in (L x W x H)

Fitment

Jeep Gladiator (JT)

2022 Jeep Gladiator (JT)

2021 Jeep Gladiator (JT)

2020 Jeep Gladiator (JT)

Options

Skyjacker 4.5in. Component Box with Dual Rate Long Travel Front and Rear Coils Options

Part Number	Catalog #	Rubicon or Non-Rubicon	Engine Type					Price
G452LTD	16117-2538	Non-Rubicon	EcoDiesel Engine					$1,032.99
G452RLTD	16117-2542	Rubicon	EcoDiesel Engine					$1,032.99
