Vision X Shocker Dual Action LED Light Bar

Description

Have your Jeep shock the night with the Vision X Shocker Dual Action LED Light Bar! Vector Reflector Technology is used for the top half of this light bar to project a broad spot beam down the trail. The bottom half of the light bar utilizes a Photon Light Core for a wide elliptical beam. The amber light option works best for cutting through dust, fog, and other inclement weather. While the race amber option features upgraded amber LED’s for 25% additional lighting distance.

The Shocker Dual Action LED Light Bar brings versatility and lighting power to your Jeep by allowing you to adjust your lighting to the ever-changing overland conditions with the flick of a switch.Providing you with the ultimate dual function light bar with output illuminating the front of your Jeep on the road or down the trail. Built with state-of-the-art CREE LED’s and rated at 50,000+ hours of life expectancy. Includes 3-way toggle switch and wiring harness. Available in multiple lengths.

Learn More

12″ Shocker Specifications:

• Back-Lit Halo Function (12″ Length Only)
• Raw Lumens: Broad Spot – 6,420 lm Wide Elliptical Amber – 3,550 lm | Race Amber – 3,025 lm | White – 6,945 lm
• Wattage: Broad Spot – 60W Wide Elliptical Amber – 70W | Race Amber – 100W | White – 100W
• Amp Draw @ 12V: Broad Spot – 5A Wide Elliptical Amber – 5.8A | Race Amber – 8.3A | White – 8.3A

20″ Shocker Specifications:

• Raw Lumens: Broad Spot – 12,840 lm Wide Elliptical Amber – 7,100 lm | Race Amber – 6,050 lm | White – 13,890 lm
• Wattage: Broad Spot – 125W Wide Elliptical Amber – 140W | Race Amber – 200W | White – 200W
• Amp Draw @ 12V: Broad Spot – 10.42A Wide Elliptical Amber – 11.67A | Race Amber – 16.67A | White – 16.67A

30″ Shocker Specifications:

• Raw Lumens: Broad Spot – 19,260 lm Wide Elliptical Amber – 10,650 lm | Race Amber – 9,075 lm | White – 20,835 lm
• Wattage: Broad Spot – 195W Wide Elliptical Amber – 220W | Race Amber – 300W | White – 300W
• Amp Draw @ 12V: Broad Spot – 16.25A Wide Elliptical Amber – 18.33A | Race Amber – 25A | White – 25A

40″ Shocker Specifications:

• Raw Lumens: Broad Spot – 25,680 lm Wide Elliptical Amber – 14,200 lm | Race Amber – 12,100 lm | White – 27,780 lm
• Wattage: Broad Spot – 250W Wide Elliptical Amber – 300W | Race Amber – 380W | White – 380W
• Amp Draw @ 12V: Broad Spot – 20.83A Wide Elliptical Amber – 25A | Race Amber – 31.67A | White – 31.67A

Installation Notes

Installation Difficulty:
Level 2 Intermediate
Installation Time: Less than an hour

Parts Included

Warranty

Limited Lifetime Warranty

Specs

For 12 Inch Amber White:

For 12 Inch White White:

For 12 Inch Race Amber White:

For 20 Inch Amber White:

For 20 Inch White White:

For 30 Inch Amber White:

For 30 Inch White White:

For 30 Inch Race Amber White:

For 40 Inch Amber White:

For 40 Inch White White:

Options

Vision X Shocker Dual Action LED Light Bar Options
